Western Digital Ultrastar Data60 - Psu; PSU Specifications

User Guide
2. Components
2.3 PSU
2.3 PSU
Figure 19: Ultrastar Data60 PSU
The Ultrastar Data60 contains redundant 1600W
Power Supply Units (PSUs). Each PSU requires an
input voltage between 200 - 240 VAC. The PSUs
are 80 PLUS Platinum certified and utilize C14 power
cable receptacles.
2.3.1 PSU Specifications
Specification Value
Power Output 1600W
80 PLUS Standard Platinum
Input Voltage 200 - 240 VAC
Connector Type C14
Number per Enclosure 2
Part Number 1EX0434
Hot Swappable? Yes
FRU or CRU? CRU
Weight 1 kg / 2.2 lbs.
