4. Management
4.4 OOBM Management Overview
• Setting = 01 (DHCP)
• IP Address = 0.0.0.0
• Netmask = 0.0.0.0
• Gateway = 0.0.0.0
Viewing the OOBM Network Configuration
Step 2 : To view the OOBM network configuration, enter the following:
sg_wr_mode <dev> --dbd --page=0x23,0x01
This returns:
e3,01,00,30,03,00,00,00,<IOM A Setting>,00,00,00,<IOM A IPaddr>,<IOM
A Netmask>,<IOM A Gateway>,00,00,00,<IOM B Setting>,00,00,00,<IOM B
IPaddr>,<IOM B Netmask>,<IOM B Gateway>
• <IOM> = 03 (IOMA & IOMB)
• <IOM A Setting> = 00 (static) or 01 (DHCP)
• <IOM A IPaddr> = The IP address in four pairs of two-digit hex codes
• <IOM A Netmask> = The netmask, in four pairs of two-digit hex codes
• <IOM A Gateway> = The gateway, in four pairs of two-digit hex codes
• <IOM B Setting> = 00 (static) or 01 (DHCP)
• <IOM B IPaddr> = The IP address in four pairs of two-digit hex codes
• <IOM B Netmask> = The netmask, in four pairs of two-digit hex codes
• <IOM B Gateway> = The gateway, in four pairs of two-digit hex codes
The result, after setting the two static addresses in Changing the OOBM Network Configuration
(page 176):
e3,01,00,30,03,00,00,00,00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01,
00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01 <dev>
The result, when IOM B is not booting (no IP):
e3,01,00,30,03,00,00,00,00,00,00,00,C0,A8,00,0A,FF,FF,FF,00,C0,A8,00,01,
00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00 <dev>
Note: Setting an invalid gateway will result in that field being zeroed-out.
4.4.2 Upgrading Firmware with OOBM
The following procedure should be followed to upgrade the firmware of the Ultrastar Data60 using the
OOBM API.
Step 1 :
Open a web browser, go to: https://portal.wdc.com/Support/s/, and download the firmware
package for the Ultrastar Data60 .
Step 2 :
Extract the downloaded zip file and place file in a location that is accessible to the Ultrastar
Data60 .
Step 3 : Make a POST call to the UpdateService object using the SimpleUpdate action.
