page 1 – 2
IP-12/IP-16 / Dec 2014
GENERAL INFORMATION
General Information
Introduction
The Wheatstone twelve- or sitxeen-input IP-12/IP-16 control surface offers a great
way for a small to medium radio operation to enter the world of networked audio.
Tapping into the power of WheatNet-IP Intelligent Network technology through the
use of the included WheatNet-IP 88cb audio Console Blade/mix engine, it’s a perfect
low-cost, small-footprint solution.
Each of the 12/16 input modules is equipped with an LED source name display
and an A/B source selector whose sources can be set via a rotary encoder in the master
section. Each input module has access to four program busses and has cue and talkback
switches. A 100mm long-throw fader and lighted channel ON/OFF switches round out
the module. The master section offers control room, studio, and headphone controls
with source selection, and an onboard headphone jack and amplier. Timer controls, a
master talkback button, and a built-in cue speaker with volume control are provided.
There are four event switches and six programmable buttons available for user functions.
The meterbridge has three stereo pairs of bright 30-segment horizontal LED bargraph
meters, as well as an on-board timer with controls located in the master section.
