Wheatstone IP-12 - Logic Ports

page 4 – 7
IP-12/IP-16 / Dec 2014
WHEATNET-IP 88cb CONSOLE BLADE
RJ‑45 C Pin 1 – HI
RJ‑45 C Pin 2 – LO
RJ‑45 C Pin 3 – HI
RJ‑45 C Pin 6 – LO
RJ‑45 D Pin 1 – HI
RJ‑45 D Pin 2 – LO
RJ‑45 D Pin 3 – HI
RJ‑45 D Pin 6 – LO
PGM OUT DIGITAL RJ-45
RJ‑45 A Pin 1 – HI
RJ‑45 A Pin 2 – LO
RJ‑45 B Pin 1 – HI
RJ‑45 B Pin 2 – LO
RJ‑45 C Pin 1 – HI
RJ‑45 C Pin 2 – LO
RJ‑45 D Pin 1 – HI
RJ‑45 D Pin 2 – LO
Logic Ports
The WheatNet-IP 88cb has two LOGIC I/O RJ‑45 connectors that provide 12 Universal
logic ports.
LOGIC I/O 1 - 6 RJ-45
RJ‑45 Pin 1 – Digital Ground
RJ‑45 Pin 2 – Logic 1 In/Out
RJ‑45 Pin 3 – Logic 2 In/Out
RJ‑45 Pin 4 – Logic 3 In/Out
RJ‑45 Pin 5 – Logic 4 In/Out
RJ‑45 Pin 6 – Logic 5 In/Out
RJ‑45 Pin 7 – Logic 6 In/Out
RJ‑45 Pin 8 – +5V Digital
LOGIC I/O 7 - 12 RJ-45
RJ‑45 Pin 1 – Digital Ground
RJ‑45 Pin 2 – Logic 7 In/Out
RJ‑45 Pin 3 – Logic 8 In/Out
RJ‑45 Pin 4 – Logic 9 In/Out
RJ‑45 Pin 5 – Logic 10 In/Out
RJ‑45 Pin 6 – Logic 11 In/Out
RJ‑45 Pin 7 – Logic 12 In/Out
RJ‑45 Pin 8 – +5V Digital
PGM AES C Out
PGM AES D Out
PGM AES A Out
PGM AES B Out
PGM C Lt Out
PGM C Rt Out
PGM D Lt Out
PGM D Rt Out
