Wheatstone IP-12 - Outputs

page 4 – 6
IP-12/IP-16 / Dec 2014
WHEATNET-IP 88cb CONSOLE BLADE
Outputs
The WheatNet‑IP 88cb provide four stereo analog outputs on RJ‑45 connectors,
four digital AES formatted outputs on RJ‑45 connectors, cue and headphone outputs
on an RJ‑45 connector and on 1/4" jacks, and control room and studio monitor outputs
on XLR male connectors.
MIC OUTS RJ-45
RJ‑45 Pin 1 – HI
RJ‑45 Pin 2 – LO
RJ‑45 Pin 3 – HI
RJ‑45 Pin 6 – LO
CUE/HDPN OUT RJ-45
RJ‑45 Pin 1 – HI
RJ‑45 Pin 2 – LO
RJ‑45 Pin 3 – HI
RJ‑45 Pin 6 – LO
RJ‑45 Pin 4 – HI
RJ‑45 Pin 5 – LO
RJ‑45 Pin 7 – HI
RJ‑45 Pin 8 – LO
STUDIO OUT XLR
XLR#1 Pin 1 – SH
XLR#1 Pin 2 – HI Studio Lt Out
XLR#1 Pin 3 – LO
XLR#2 Pin 1 – SH
XLR#2 Pin 2 – HI Studio Rt Out
XLR#2 Pin 3 – LO
CR OUT XLR
XLR#1 Pin 1 – SH
XLR#1 Pin 2 – HI CR Lt Out
XLR#1 Pin 3 – LO
XLR#2 Pin 1 – SH
XLR#2 Pin 2 – HI CR Rt Out
XLR#2 Pin 3 – LO
PGM OUT ANALOG RJ-45
RJ‑45 A Pin 1 – HI
RJ‑45 A Pin 2 – LO
RJ‑45 A Pin 3 – HI
RJ‑45 A Pin 6 – LO
RJ‑45 B Pin 1 – HI
RJ‑45 B Pin 2 – LO
RJ‑45 B Pin 3 – HI
RJ‑45 B Pin 6 – LO
Mic 1 Out
Mic 2 Out
HDPN Lt Out
HDPN Rt Out
Cue Lt Out
Cue Rt Out
When using the microphone
preamplifiers, a jumper must
be connected from the MIC
OUTS to the desired analog
input port (1-4).
PGM A Lt Out
PGM A Rt Out
PGM B Lt Out
PGM B Rt Out
