Whirlpool CHW9050 User Manual

4-36
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the door lock assembly.
(See page 4-16).
4. Remove the control panel cover.
(See page 4-2).
5. Remove the lower service panel
(See page 4-21).
6. Remove two 1/4” hex head screws, that
were hidden by the lower service panel, that
secure the bottom of the front panel to the
washer side panels.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
FRONT PANEL
7. Remove two 1/4” hex head screws, that
were hidden by the control panel cover,
that secure the top of the front panel to the
washer side panels.
n If not removed earlier, the door lock
assembly is attached to the inside of the
front panel. Disconnect the wire connectors
to the door lock assembly to be able to
remove the front panel completely.
Two 1/4”
Hex Head
Screws
Top left front corner
Top right front corner
Two 1/4” Hex Head Screws

Whirlpool CHW9050 Specifications

General

Brand	Whirlpool
Model	CHW9050
Type	Top Load Washer
Color	White
Wash Cycles	12
Steam Function	No
Energy Star Certified	Yes
Wash Action	Impeller
Delay Wash Option	Yes
Quick Wash Cycle	Yes
Deep Water Wash Option	Yes
Built-In Water Faucet	No
Water Level Settings	Automatic
