2-6
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. There are 4 shipping bolts in the back panel
of the washer that support the suspension
system during transportation.
2. Use a 1/2” wrench to loosen each of the
bolts.
3. Once the bolts are loose, move each one to
the center of the hole and remove the bolt,
including the plastic spacer covering the
bolt.
4. Once all 4 bolts are removed, push the
power cord plug into the hole in the back of
the washer and pull the cord out of the hole
at the other side.
5. Cover the holes the power cord came out of
with the plastic caps attached to the back of
the washer.
6. Pull the drain hose from inside of spin
basket and install, with a clamp, on drain
port at top right corner of the back panel.
7. Cover the holes the shipping bolts came out
of with the plastic hole plugs shipped with
the washer.
SHIPPING BOLTS -
REMOVE
Excessive Weight Hazard
Use two or more people to move and
install washer.
Failure to do so can result in back or
other injury.
WARNING
1. If washer must be transported after the
shipping bolts have been removed, at least
2 shipping bolts must be re-installed to
make sure the washer components are not
damaged due to movement of the weights
and the outer tub.
2. Unplug washer or disconnect power.
3. Turn off the water supply to the washer.
4. Remove the back panel from the washer.
5. Assemble tub spacers onto shipping bolts.
Insert each shipping bolt assembly through
hole in the back brace and into the hole in
the outer tub. Tighten with a 1/2” wrench.
6. Slide shipping bolt towards the outer edge
of the washer before tightening the bolt
completely to secure the spacer in place.
7. Reinstall the back panel before transporting
the washer.
SHIPPING BOLTS -
REINSTALL
Excessive Weight Hazard
Use two or more people to move and
install washer.
Failure to do so can result in back or
other injury.
WARNING
To Next Page
