4-18
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Pull the washer away from the wall.
4. Remove the rear panel from the washer.
See ("REMOVING THE MOTOR CONTROL
UNIT" for procedure.)
REMOVING THE TEMPERATURE SENSOR & HEATER
5. To remove the temperature sensor:
a) Remove 1 screw holding the cover in place.
b) Disconnect the wire connectors from the
heater and temperature sensor.
b) Loosen the 10 mm nut and pull the tem-
perature sensor out of the heater.
6. To remove the heater:
a) Remove the temperature sensor from
the heater (see step 5).
b) Loosen (do not remove) the 10 mm nut
on the heater.
c) Disconnect the two heater wires and the
ground connector wire from the heater.
d) Pull the heater out of the tub opening.
e) When reinstalling the heater, be sure that
the element is held in place by the spring
clip inside the housing.
Temperature Sensor & Heater
Remove Screw
Cover
Temperature Sensor
Wire Connector
Heater Connectors
10 mm Nut
Pull Temperature
Sensor Out Of
Heater
10 mm Nut
Ground Terminal
Heater
Spring Clip
To Next Page
