4-14
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
REMOVING THE DRAIN PUMP
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the front panel, see ("REMOVING THE
DOOR SWITCH ASSEMBLY FRONT PANEL AND
BELLOWS")
4. Using a shallow pan to catch the water, un-
screw the filter from the drain pump, and
drain the water from the sump.
8. Lift the wire cover on the drain pump, and
disconnect the wire connector from the ter-
minals.
10. Remove the wires from the clip, and remove
the drain pump from the washer.
5. Loosen the clamp and remove the pump-to-
tub hose from the drain pump.
REASSEMBLY NOTE: When you reconnect the
hoses, align their tab(s) with the marks on the
drain pump.
6. Pull the rubber tab straight out to free the
"keyhole" bracket and remove the front of
the drain pump.
7. Work the pump side to side while pulling
forward to release the "keyholes" at the
back of the pump from the rubber isolators.
Drain Pump
Drain Pump Filter
Pump-To-Tub Hose
Clamp
Clamp
Rubber Isolators
R
ubber Tab
Connector
Cover
REMOVING THE ECO VALVE
