Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the top cover and the console
("REMOVING THE DISPENSER DRAWER, TOP AND
CONSOLE ASSEMBLY"
for the procedures).
4. Open the washer door.
5. Using a small screwdriver or a pair of long-
nosed pliers, pull the tension spring on the
retaining wire out from around the front of
the bellows, and remove the wire.
Tension Spring
6. To remove the door switch assembly:
a) Pull the bellows off the lip of the front panel
beside the door switch assembly just enough
to access the switch assembly.
b) Remove the two T-20 Torx screws from
the door switch assembly.
Water Inlet
Bellows
Door Switch
Door Switch Screws
c) Pull the door switch assembly out and
turn it over so that you can access the
connectors.
d) Unlock the tabs and disconnect the wire
connectors from the door switch termi-
nals, then remove the assembly.
Connectors
REMOVING THE DOOR SWITCH ASSEMBLY FRONT PANEL AND BELLOWS
