4-6
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the water hoses from the hot and
cold water inlet valve.
4. Remove the top cover (see "
REMOVING
THE DISPENSER DRAWER, TOP
AND CONSOLE
ASSEMBLY"
for the procedure).
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
REMOVING THE WATER INLET VALVE
5. Lift the locking tabs with a small-blade
screwdriver and pull the wire connectors
out of the hot and cold water inlet valve
solenoid terminal holders.
7. At the rear of the washer, remove the screw
from the water inlet valve. Slide the valve to
the right, and push it into the washer off the
rear panel.
6. Loosen the clamp, and pull the water inlet
hose off the water valve.
Water Inlet Valve Screw
Water Inlet Valve
Water Inlet Valve
Inlet Hose
& Clamp
Connector Tabs
Connectors
To Next Page
