POSITIONIT POSITIONERS
1-4 PM-01011-A
October 2023
1.5 Specifications
Table 1-1 lists specifications for the positioner. Table 1-2 lists specifications for the default
joystick controller.
Table 1-1 Positioner Specifications
PI-35
PI-75
PI-150
Payload Capacity
35 ft.-lb. (47 Nm)
75 ft.-lb. (101 Nm)
150 ft.-lb. (202
Nm)
Overall Height
9.8 in. (248mm)
11.32 in. (287.7
mm)
11.32 in. (287.7
mm)
Overall Width
10.8 in. (273mm)
9.7 in. (246.0 mm)
12.4 in. (314.0
mm)
Weight
21 lb. (9.5kg)
35 lb. (15.9 kg)
37 lb. (16.8 kg)
Operating Temperature
-40°F to 140°F (-40°C to 60°C)
Pan Degrees of Rotation
± 400° (± 200°)
Tilt Degrees of Rotation
180° (± 90°)
Pan Speed (Proportional)
1 to 12° / second
1 to 6.5° / second
Tilt Speed (Proportional)
1 to 12° / second
1 to 5.5° / second
Backlash
≤ 0.15°
Repeatability
≤ 0.3°
Maximum Continuous
Power
44 W
Maximum Continuous
Current
1.85 amps
Input Voltage
24 VDC
Protocol
Pelco D used (Pelco P available)
Ingress Protection Rating
IP68
Baud Rate
2,400 bps
Table 1-2 Default Joystick Controller (P/N: 5098901) Specifications
Specifications
Input Voltage
12 VDC
Rating Power
0.5 watts
Communication Interface
RS485
Communication Frequency
2,400 bps used (4,800; 9,600; 19,200 bps available)
Operating Temperature
32°F to 122°F (0°C to 50°C)
Dimensions (W x H x L)
5.4 x 4.2 x 6.6 in. (136 x 105 x 168 mm)
Weight
0.89 lb. (0.40 kg)
Protocol
Pelco D used
