POSITIONIT POSITIONERS

PM-01011-A 2-5

October 2023

3. Carefully pull away the removable plug and gently pull out the attached wires and

gasket behind it (Figure 2-4).

Figure 2-4 Carefully Pull Out the Removable Plug, Gasket, and Attached Wires

4. Disconnect the wires from the positioner. The wires are connected to the positioner

with a quick connect (Figure 2-5).

Figure 2-5 Quick Connect

Plug

Connector

Gasket

Wires

Quick

Connect
