5.2.4 Baud Rate
When the controller is powered on, the baud rate will be displayed. The baud rate should be
2400 bps. If necessary, reset the baud rate to 2400. A quick guide to resetting the baud rate
can be found in Table 5-4.
Table 5-4 Resetting the Baud Rate
1. Keyboard setup
2. Dome setup
3. Protocol select
4. Exit menu
1. Set KB ID(1-64):
2. Set baudrate: 2400
3. Joy-calibrate
4. About Keyboard
1. Set KB ID(1-64):
2. Set baudrate: 2400
3. Joy-calibrate
4. About Keyboard
Move the joystick down
until the number beside
<Set baudrate> reads
2400, then move the
joystick right.
To reset the baud rate:
1. Press [Menu] for (2) seconds. The Menu screen will appear (Figure 5-2).
2. While remaining on <Keyboard setup>, move the joystick to the right to go to the
submenu. The Keyboard setup screen (Figure 5-5) will appear. The number beside
<2. Set baudrate:> may vary.
1. Set KB ID(1-64):
2. Set baudrate: 2400
3. Joy-calibrate
4. About Keyboard
Figure 5-5 Keyboard Setup Screen
3. Navigate to <Set baudrate> and move the joystick to the right. The screen will remain
the same, but the number beside <2. Set baudrate:> will be selected.
4. Move the joystick forward or backward to adjust the baud rate.
5. Move the joystick to the right to save the baud rate. <Success!> will briefly flash at
the bottom of the LCD screen and the display will return to the Menu screen (Figure
5-2). The setting is saved.
