Winkhaus BlueMatic EAV3 - Center Keep FRA; Magnetic Trigger for Center Keep FRA

blueMatic EAV 504474427Installation, Operating and
Maintenance Instructions
2
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
Magnetic trigger for center keep FRA ... AV ...
Magnetic trigger for contact-free magnetic
release for autoLock AV3. Can be retrofitted in
center keeps FRA ... AV ... with magnet hole.
T-G MAGNETAUSLÖSER  MV
AV

T-G MAGNETAUSLÖSER  MV
AV

T-G MAGNETAUSLÖSER  UMV
AV

T-G MAGNETAUSLÖSER 
UMV AV

Center keep FRA ... AV ...
Center keep for latch and deadbolt for retro-
fitting of magnetic trigger and daytime latch
"TAFA". Designed for use with PVCu, Aluminum
and Timber/composite entrance doors.
Select the respective keeps according to the
profile systems in the current program manual
(see program overview keep - group 2).
