12 V = Delivery status
24 V
Caution!
blueMatic EAV must
be operated with 12 V.
Notice: Check the proper position of the jumper before starting
operation!
504474450
3
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
Figure 3.5.1-3: Adjustment of the jumper for voltage selection
• The default setting of the jumper is 12 V.
• The wireless receiver can be adjusted from 12 V to 24 V via the jumper.
