Notice: The positioning of
frame power supply and
cable transition on the hinge
side is recommended, either
between lower / middle door
hinge or in each case approx.
10 cm above / below the
middle door hinge.
504474455
3
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
Figure 3.6.2-2: Installation blueMatic EAV with Fingerprint ekey home micro
„Micro-Control unit, installed in the profile“ and frame power supply (sash side)
Do
not connect
external
voltage!
230 V AC
yellowgrey  output signal swing door opener
(optional) only by motor housing
swing door
greenwhite  input for external potential-free
contact (eg unlocking via inter-
comopen button)
Notice! max  m extendable
(min  mm

)
Description Art.-No.
Sash part cable transition
T-KÜ-T FT EKEY MICRO
(PLUS) M

Frame part cable transi-
tion T-KÜ-T RT KABEL
M RNT for frame power
supply

Motor housing EAV for
retrofitting mechanical
locking system AV
standard

Frame power supply
T-NETZTEILRAHM  V
DC  A (AS)

to ekey WH-EAV
Set Integra micro with App
ekey

ekey Adapter micro WH EAV WH
KÜ Y-connection from cable tran-
sition to motor housing and control
unit SE micro plugnplay
Fingerprint ekey home FS IN  T
BT  Decor element FS IN ED
Control unit ekey home SE micro 
ekey KAB A  m x  RJCP
Connection between fingerprint and
control unit
white   V DC
brown  V
green external opening signal
yellow
grey
pink (unscript)
}
signal swing door
opener
