blueMatic EAV Installation, Operating and
Maintenance Instructions
Errors Indication Possible cause Troubleshooting
the motor stops • the door is warped
• the contact pressu-
re is too high
•
the lock is too tight
• adjust the door
• check the ope-
ration via profile
cylinderhandle
the motor fun-
ctions but the
door cannot be
opened
• the main bolt is
unlocked via profile
cylinder
• Operating forces
too high faulty
installation
• draw the main bolt
back again via the
profile cylinder
• check installation
(keep alignment
air gap etc)
Power failure
whenduring
a) the door is
locked
• the door can be
operated mecha-
nically (profile
cylinderhandle)
b) the door is
open lock is
unlocked
the door is pos-
sibly not held
by the latch
• the motor is not in
starting position
• close the door by
pre-locking the
main bolt if neces-
sary
c) the un-
locking
procedure
when the door
is locked again
possibly the
hook main bolt
do not lock
completely
• the motor is not in
starting position
• door can be ope-
rated mechanically
(profile cylinder
handle) if motor
has returned to
starting position 
completely func-
tions
EAV does not
operate with
remote but LED
is illuminating
door doesn‘t
open
• remote battery
dead
• replace battery in
remote control
• out of range to the
remote control
• operate remote
control within
 mtrs
(unostructed)
• remote control not
autthorized
• check remote
control program-
med
