T-LB ENDKAPPE STK/RNT HOLZ H4 R12 SW
(5035742)
Cover for frame power supply and tappet
contact (frame side) with 12 mm radius, e.g.
for timber, 4 mm air gap, in packages of 10
pieces in a plastic bag
Cover STK/RNT
T-ABDECKUNG KÜ-T1 RT R8 RAL 7035
(5040517)
Cover Strip T-KÜ-T1 RT R8 (separate), serves
to cover the profile hole on the frame side,
when using the frame part T-KÜ-T1 RT
KABEL 0,6M RNT
Cover Strip
T-LB VERL.KABEL 0,25 M RNT ZU KÜ-T1
(5066122)
plug-in extension between frame power
supply RNT and frame part cable transition
T-KÜ-T1 RT KABEL 0,6M RNT
Extension cable
Connecting cable 6 m for
motor
T-HT ANSCHLUSSKABEL 6M FÜR MOTOR
(2522881)
Cable 6 m (5 x 0.25 mm)
1st Cable end with plug for motor housing EAV
2nd Cable end with wire end sleeve
Use as an alternative to cable transition
T-KÜ-T1 FT 2/3,5/4,5 M.
