118
WPS-365-DVR-9CH & 16CH Installation and Users Manual
11. APPENDIX A – SPECIFICATIONS
Specications are subject to change without notice
SECTION FUNCTION WPS-365-DVR-9CH WPS-365-DVR-16CH
System
Multi-Operation
Hexaplex - Simultaneous Live
View, Record, Playback, Control,
Remote Access, Backup
Hexaplex - Simultaneous Live
View, Record, Playback, Control,
Remote Access, Backup
Dual Stream Yes, RSTP Yes, RSTP
Video
Input 9CH, BNC 16CH, BNC
Video Loop Outputs Yes - 9 Yes - 16
Main Monitor HDMI/VGA/BNC HDMI/VGA/BNC
HDMI Yes (True 1920 x 1080 60Hz) Yes (True 1920 x 1080 60Hz)
Call Monitor Yes Yes
Audio Input / Output
4 RCA in, 2 RCA out, 1 HDMI out 4 RCA in, 2 RCA out, 1 HDMI out
Record
Compression
H.264 Main Prole
ADPCM Audio
H.264 Main Prole
ADPCM Audio
Supported Resolutions 960H/Full-D1/Half-D1/CIF 960H/Full-D1/Half-D1/CIF
Max Record Resolution 960H all channels 960H all channels
Frame rate (FPS) &
Resolution
240@960H
270 @ 720x480
270 @ 720 x 240
270 @ 360 x 240
240@960H
360 @ 720x480
480 @ 720 x 240
480 @ 360 x 240
Mode
Continuous/Manual/Schedule/
Alarm/Motion
Continuous/Manual/Schedule/
Alarm/Motion
Motion Detection
Yes, with congurable detection
area & sensitivity
Yes, with congurable detection
area & sensitivity
Display
Resolution
HDMI/VGA: up to 1920x1080
BNC: 720x480
HDMI/VGA: up to 1920 x 1080
BNC: 720 x 480
Sequential Switch User adjustable User adjustable
Split Windows 1/4/7/9 1/4/7/9/10/13/16
Search
Time/Event (Alarm, Motion,
Video loss), Smart search/POS/
PC
Time/Event (Alarm, Motion,
Video loss), Smart search/POS/
PC
Storage
Hard Drive (1) 1TB SATA (WD Purple)
(1) 2TB SATA (WD Purple)
Hard Drive Extension 1 eSATA connector (non-RAID) 1 eSATA connector (non-RAID)
Internal Hard Drive Bays 4 4
ESATA Connection 1 1
USB Ports 2 (1 for mouse) 2 (1 for mouse)
Internal DVD+RW drive No No
Alarm
Contact Inputs/Relay
Outputs
16 in/4 out (2 NO, 2 NC) 16 in/4 out (2 NO, 2 NC)
Event Log
Alarm, Motion, Video Loss,
System (HDD failure, HDD full, No
record, login/logout, Power on/
off
Alarm, Motion, Video Loss,
System (HDD failure, HDD full, No
record, login/logout, Power on/
off
