WPS-365-DVR-9CH & 16CH Installation and Users Manual
To navigate and operate this menu:
 •▲▼◄►
Press these buttons on the front panel of the DVR or remote control to select an item. Alternatively use
the mouse to select an item.
 •NUMERIC
Press these buttons on the front panel of the DVR or remote control to select an alarm input.
 •COPY( )
Press the COPY button on the front panel of the DVR or remote control to copy the Alarm input settings of
the focus camera to all of the cameras.
 •ESC
Press the ESC button on the front panel of the DVR or remote control to escape from this menu and
return to the main menu. Alternatively use the mouse to exit the sub menu by clicking on the “X.” If
the contents in this menu have been modied, a Save dialog box will be displayed requesting the user
to save the changes. Press ENTER on the front panel of the DVR or remote control to exit and save, ESC
to exit without saving. Another method to escape is to use the mouse to “right-click,” and exit the sub
menu.
Thefollowingisabriefdescriptionforeachiteminthesubmenuanditsspecicoperations:
 •NORMALSTATE
Press +/- buttons on the front panel of the DVR or remote control to select N/A, Close or Open. The
type of sensor connected to the DVR will determine the setting. For example, motion detectors typically
are normally open while door contacts are normally closed. Select N/A (Not Available) if the input is
not used and the following items will not be adjustable. The default setting is Open.
 •FOCUSCAMERA
The camera associated with the alarm input.
•DURATION
Set the length of time the buzzer and the corresponding Alarm Out relay will remain triggered once video
loss is detected for this camera. The Buzzer and Alarm Out relay will reset immediately once video signal
is restored. Press +/- buttons to adjust the value from 3 seconds to 60 minutes or ‘-‘ for indenite requiring
an Alarm Reset.
 •GOTOPRESET
The GOTO Preset feature works in conjunction with the Camera To Go setting and denes the
preset position the Camera To Go PTZ camera will go to when video signal is lost for this camera.
For more details about preset positions for PTZ cameras, refer to Section 7.
 •PRE-RECORD
Pre-Record denes how much time the DVR will record before video loss is detected. The Pre Record FPS
set in Section 6.2 determines the frame rate of this recording. Press +/- buttons on the front panel of the
DVR or the remote control to adjust the value from 0 to 10 seconds. Alternatively use the mouse to adjust
this setting.
Notethattheactualpre-recordtimemaybeshorterthanthevaluesetifthetotalsizeofthepre-record
  videoexceedsthepre-recordvideobuffer.
 •POST-RECORD
Dene how much time the DVR will record after motion is detected. The Post Record FPS set in Section
6.2 determines the frame rate of this recording. Press +/- buttons on the front panel of the DVR or on the
remote control to adjust the value from 0 to 60 minutes. Alternatively use the mouse to adjust this setting.
 •ALARMOUT
Dene which Alarm Output will be triggered when video loss for this camera is detected. Press +/-
buttons to select N/A for none or either of the Alarm Outputs (1 for NC or 2 for NO). Alternatively use the
mouse to adjust this setting.
 •BUZZER
By default, the internal buzzer is enabled to sound when video loss for the camera is detected.
Highlight this setting and press ENTER or +/- to enable or disable this item. Alternatively use the mouse
to left-click on this item. Alternatively use the mouse to left-click on this item.
