Ci7 XX0 BENCHTOP S P ECTROPHOTOMETER
13
Specular Excluded (SCE)
• Illuminates when a specular excluded measurement is selected.
Total (T) – excludes Ci7500 series
• Illuminates when a total transmission measurement is selected.
Direct (D) - excludes Ci7500 series
• Illuminates when a direct transmission measurement is selected.
Haze (H) - excludes Ci7500 series
• Illuminates when a haze measurement is selected.
D65 Illuminate
• Illuminates when it is UV calibrated to a D65 UV illumination condition.
UV Excluded (
)
• Illuminated when one of the UV filters fully blocks the UV component in the lamp to fully
exclude UV illumination.
Custom (
*
)
• Illuminated when a user-defined D65 or other UV condition is selected.
400
• The 400 nm UV cutoff filter is in use. This filter is adjustable and can be used to calibrate
UV conditions.
420 - excludes Ci7500 series
• The 420 nm UV cutoff filter is in use. This optional filter is adjustable and can be used to
calibrate UV conditions.
460 - excludes Ci7500 series
• The 460 nm UV cutoff filter is in use. This optional filter is not adjustable and can only be
set to fully exclude UV illumination.
Power “standby” button and indicator
• Refer to Powering the Instrument earlier in this section.
