Operation
Power Supply Operation
Release 3.0 101
To set the current limits:
Step # Do This You Will See
1 ERROR MSGS
2 until you see the “SETPT
LIMIT” option
SETPT LIMIT
3 Voltage Limit
4 Current Limit
5 High 0A
6 Use the Current knob, arrow keys, or
numeric keypad to enter a value. The
value must be within 0A to 103% of
the unit’s rated current.
High #####A
7 Low 0A
The Maximum setting is saved and
the Minimum setting appears.
8 Use the Voltage knob, arrow keys, or
numeric keypad to enter a value. The
value must be within 0A to 103% of
the unit’s rated current.
Low #####A
9
The setting is saved and the display
returns to its default operating mode.
MENU
ENTER
ENTER
ENTER
ENTER
