Specifications and Characteristics
Output Performance Specifications
Release 3.0 237
Output Performance Specifications
These specifications define the electrical performance specifications of the power
supply output. These specifications apply to both local and remote sense
configurations, except where noted. These specifications apply to all programming
sources, except where noted.
Rated Output Range
Efficiency
• Typical 89% efficiency at nominal line voltage and ambient temperature.
• Minimum 82% efficiency. Specific minimum efficiency limits are model
dependent.
Load Regulation
Line Regulation
Programming Range for Voltage, Current, and Power
OVP Programming Range
• 0–103% of maximum rated voltage
Voltage 0–100%
Current 0–100%
Voltage 5 mV + 0.05% of Vmax
Current 6000 W: 20 mA + 0.1% of Imax
12000 W: 40 mA + 0.2% of Imax
Power 1% of Pmax
Voltage 0.01% of Vmax
Current 6000 W: 0.05% of Imax
12000 W: 0.1% of Imax
Power 1% of Pmax
Voltage and Current From 0–103% of the rated maximum output
Power From 3–103% of the rated maximum output
