Operation
Power Supply Operation
78 Operating Manual for XDC Series Power Supply
The following table demonstrates how to set and save current and voltage settings:
Change
Stored
Settings
To change a stored setting, overwrite it with a new setting, or select the setting, press
CE and hold it for a few seconds to clear the setting from memory.
Step # Do This You Will See
1 Set #####V
2 Turn the Voltage knob or use the
numeric keypad to enter a voltage
setpoint.
Set #####V
Your voltage setting appears on the
display.
3
Your voltage setting is saved.
4 Set #####A
5
Turn the Current knob or use the
numeric keypad to enter a current
setpoint.
Your current setting appears on the
display.
6
Set 1 (unused)
1
1. (unused) appears with Set 1 if there are no saved settings in the system. Press Enter to save
your setting as Set 1. If (unused) does not appear, then you can overwrite Set 1 with your new
setting or use the numeric keypad or arrow keys to find the next unused set number. You can
also press CE to clear an existing setting and then press ENTER to replace the cleared setting
with your new setting.
7
Set 1
Your voltage and current setting is now
saved as Set 1.
VOLTAGE
ENTER
CURRENT
STORE
ENTER
