Operation
Power Supply Operation
88 Operating Manual for XDC Series Power Supply
Programming
a Sequence
This option allows you to set up command programs for automated operation.
To program a sequence:
:
Note In the following procedure, only change the default setpoints if required. Otherwise
simply press ENTER to accept.
Step # Do This You Will See
1 ERROR MSGS
2
or 6 times
AUTO SEQ PGM
3 Sequence 1
4
or . Use the scroll
keys to select a sequence to work
with.
Sequence #
5 Edit Sequence
6
Edit mode is selected
Step 1
7 Edit Step
8
Enter the step voltage
setpoint
S01 ####V
9
Enter the step current
setpoint.
S01 ####A
10
Enter the step power.
S01 ####W
11
Enter the step OVP
level.
S01 ####V
12 Set Step Time
13
or . Use the scroll
keys to select how you want to
advance to the next step:
• Set Step Time waits for a certain
period. See the “Setting step advance
by time:” table below.
• Wait for Trig waits for a trigger event.
See the “Setting step advance by
trigger:” table below.
MENU
MENU
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
