202 Operating Manual for XDC Series Power Supply
SCPI Command Reference SCPI Command Summary
Table B.4Commands for Current Share (6000 W only)
Set Under Power
Protection
Shutdown State
[[:]SOURce][<channel>]:POWer:PROTection:UNDer:STATe
<on-off-state>
Select under power protection to shutdown
(ON) or set alarm (OFF)
Yes
Query Under Power
Protection Tripped
[[:]SOURce][<channel>]:POWer:PROTection:UNDer:TRIPped
?
Query if under power protection mechanism
has tripped
N/A
Set Over Voltage
Protection Level
[[:]SOURce][<channel>]:VOLTage:PROTection[:OVER][:LEV
el] {<voltage>|MAXimum|MINimum}
Set the over voltage protection level Yes
Query Over Voltage
Protection Tripped
[SOURce][<channel>]:VOLTage:PROTection[:OVER]:TRIPped
?
Query if over voltage protection mechanism
has tripped
N/A
Set Under Voltage
Protection Level
[[:]SOURce][<channel>]:VOLTage:PROTection:UNDer[:LEVe
l] {<voltage>|MAXimum|MINimum}
Set under voltage protection level N/A
Set Under Voltage
Protection
Shutdown State
[[:]SOURce][<channel>]:VOLTage:PROTection:UNDer:STATe
<on-off-state>
Select under voltage protection to shutdown
(ON) or set alarm (OFF)
Yes
Query Under Voltage
Protection Tripped
[[:]SOURce][<channel>]:VOLTage:PROTection:UNDer:TRIPp
ed?
Query if under voltage protection
mechanism has tripped
N/A
Set High Current Limit
[[:]SOURce][<channel>]:CURRent:LIMit:HIGH
{<current>|MAXimum|MINimum}
Set upper limit of current setpoint range (soft
limits)
Yes
Set Low Current Limit
[[:]SOURce][<channel>]:CURRent:LIMit:LOW
{<current>|MAXimum|MINimum}
Set lower limit of current setpoint range (soft
limits)
Yes
Set High Power Limit
[[:]SOURce][<channel>]:POWer:LIMit:HIGH
{<power>|MAXimum|MINimum}
Set upper limit of power setpoint range (soft
limits)
Yes
Set Low Power Limit
[[:]SOURce][<channel>]:POWer:LIMit:LOW
{<power>|MAXimum|MINimum}
Set lower limit of power setpoint range (soft
limits)
Yes
Set High Voltage Limit
[[:]SOURce][<channel>]:VOLTage:LIMit:HIGH
{<voltage>|MAXimum|MINimum}
Set upper limit of voltage setpoint range
(soft limits)
Yes
Set Low Voltage Limit
[[:]SOURce][<channel>]:VOLTage:LIMit:LOW
{<voltage>|MAXimum|MINimum}
Set lower limit of voltage setpoint range (soft
limits)
Yes
Function
SCPI Command
Description Query
Set Current Sharing Mode
[[:]SOURce][<channel>]:COMBine:CSHare:MODE
{NONE|MASTer|SLAVe}
Select current share mode Yes
Read Summed Current
[:]MEASure[:SCALar]:CURRent[:DC]? SUM
Read total current output of all current
sharing supplies
N/A
