About The XDC Power Supply
Front Panel
22 Operating Manual for XDC Series Power Supply
• Bright vacuum fluorescent display with annunciators to indicate complete
supply status at a glance
• Front panel, software-based calibration
• Fully isolated analog programming and readback capabilities
• CE Mark, CSA Certified, FCC Compliance, UL (pending)
*These features are available on 6000 Watt units when the power supply is equipped
with the optional GPIB/CANbus interface card.
Front Panel
Figure 1.1 Front Panel (6000 Watt)
1
2
3 4
5
6 7 8 1
2
