Xantrex XDC 40-150 User Manual

SCPI Command Reference
SCPI Command Summary
Release 3.0 203
Table B.5Commands for Calibration
Table B.6Command to Clear all Protection Mechanisms
Function
SCPI Command
Description Query
Restore Factory
ion
[:] CALibration[<channel>]:RESTore
Restonres the calibration to the constants set
at the factory
N/A
Change Calibration
Password
[:] CALibration[<channel>][:SECure]:CODE <codeword>
Changes the calibration security code. No
Set Calibration State
[:] CALibration[<channel>][:SECure]:STATe
<on-off-state>,<codeword>
Change calibration state (mode) Yes
Set Analog Current
Programming Input Level
[:] CALibration[<channel>]:ANALog:<5V|10V>:PROGram:CURRe
nt:LEVel {MINimum|MAXimum}
Set analog programming current calibration
level
No
Enter Analog Current
Programming Input Data
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:PROGram:CURRent[:DATA] <current>
Set analog programming current calibration
data
No
Set Analog Voltage
Programming Input Level
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:PROGram:VOLTage:LEVel {MINimum|MAXimum}
Set analog programming voltage calibration
level
No
Enter Analog Voltage
Programming Input Data
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:PROGram:VOLTage[:DATA] <current>
Set analog programming voltage calibration
data
No
Set Analog Current
Readback Output Level
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:READback:CURRent:LEVel {MINimum|MAXimum}
Set analog readback current calibration level No
Enter Analog Current
Readback Output Data
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:READback:CURRent[:DATA] <current>
Set analog readback current calibration data No
Set Analog Voltage
Readback Output Level
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:READback:VOLTage:LEVel {MINimum|MAXimum}
Set analog readback voltage calibration level No
Enter Analog Voltage
Readback Output Data
[:] CALibration[<channel>]:ANALog:
:{5V|10V}:READback:VOLTage[:DATA] <current>
Set analog readback voltage calibration data No
Set Supply Output Current
Level
[:] CALibration[<channel>]:OUTPut:CURRent:LEVel
{MINimum|MAXimum}
Set output current calibration level No
Enter Output Current Data
[:] CALibration[<channel>]:OUTPut:CURRent[:DATA]
<current>
Set output current calibration data No
Set Supply Output Voltage
Level
[:] CALibration[<channel>]:OUTPut:VOLTage:LEVel
{MINimum|MAXimum}
Set voltage output calibration level No
Enter Output Voltage Data
[:]CALibration[<channel>]:OUTPut:VOLTage[:DATA]
<voltage>
Set voltage output calibration data No
Function
SCPI Command
Description Query
Clear Output Protection
[:]OUTPut[<channel>]:PROTection:CLEar
Clears the protection mechanism. N/A
