CAMERA SYSTEM (LooksCAM2) 8 www.xenosys.co.kr
FEATURES
1. Operating Principle
Enable to record Full HD video through high quality wide-angle lens with 4.0 Mega pixel CMOS
image sensor. Easy to install and operate by every people to share the recorded video through
wireless wifi to play and download via mobile phone.
2. Electrical Rating
1) Battery Pack: 3.6 V , 10050 mAh (Lithium ion, : This symbol means Direct Current)
2) DC Power Supply: Input 100-240 V~ (50-60 Hz, 0.3 A), Output 5 V , 2200 mA
3. Protection Classification & Type against Electric Short
1) Protection Classification:
① Battery Pack: Internal Power Device
② DC Power Supply: Class II Device
2) Protection Type: N/A
4. Safety Circuit: Contains protection circuit for over-current & over-voltage
5. Operation Block Diagram: Refer to below photo
