General Procedures / Information
FaxCentre F110 12/04 6-31
Keys (Test-Code 109)
The Technician presses the buttons in the order shown under the following Key Sequence. The
display will show the next key to be pressed and automatically steps to the next one as each one
is pressed. It ignores all keys except the one requested. According to the result the technician
presses the standard buttons for OK/NOK.
Flow:
Pass:
All Keys possible to press, no anomalies occurred
Resultbytes:
00 ... Test ok
FF ... Test not done
All other bit combinations means error (anomaly occurred).
Key Sequence:
<A-Z>, <i>, <<->, <OK>, <->>, <Fax Mode>
<q>, <w>
, <e>, <r>,
<t>, <y>, <u
>, <i>,
<o>, <p>
, <
Å><a>, <s>, <d>, <f>, <g>, <h>, <j>, <k>, <l>, <.>, <Enter>
SHIFT+<Z>, <x>, <c>, <v>, <b>, <n>, <m>, < >,CTRL+<@>
<SMS>, <Redial>, <R>, <Dial>
<1>, <2>, <3>, <4>, <5>, <6>, <7>, <8>, <9>, <*>, <0>, <#>
<Res.>, <Copy>, <Clear>, <Stop>, <Start>
Table 1:
Step Status Operator UUT Display Remarks
1 Is in Testmode and wait for com-
mand
YYY TESTMODE
XX
YYY…last Testcode
XX…Errorcode or 00
2 Enter Command Keypad: 109
3 UUT shows the Key for checking
and wait for pressing
OPU KEY: xxx xxx... next Key to be
pressed
4 Press shown Key Shows and wait for the next key -
Go to Step 3 or next step if a error
occurred or the last key was shown
5 Press <START> Set Resultbyte to XX 109 TESTMODE
XX
XX = 00 and no
anomaly occurred
XX <> 00 or anomaly
occurred
