Xerox N60w User Manual

Maintenance Xerox
®
N60w Scanner
User Guide 16-21
• Visioneer Organizer AI
Uninstalling Visioneer Acuity™:
Visioneer Acuity is automatically installed when you install the scanner driver. You can also
download the Visioneer Acuity module from the support pages for your scanner at
www.xeroxscanners.com
. Visioneer Acuity is a utility with advanced image processing options to
instantly improve the visual clarity of anything you scan.
1. In the list of installed programs select Visioneer Acuity Assets.
2. Click Yes when asked to confirm you want to remove the software.
Depending on the method of installation, and your scanner model, there may be multiple entries
for Visioneer Acuity in the installed programs list. The additional entries in this list are the image
processing libraries needed to support various scanner models. These additional items will be
called “Visioneer Acuity Assets” followed by a version number. In the scenario described here,
when you want to uninstall Visioneer Acuity make sure you select and uninstall Visioneer Acuity. If
you uninstall one of the entries labeled as an “asset” you will still need to uninstall the main
Visioneer Acuity utility.
Xerox
®
N60w Scanner Specifications
Scanner Specifications
Document Requirements
Minimum Item Size 2 x 2 inches (51 x 51 mm)
Maximum Item Size 9.5 x 236 inches (241 x 5994 mm) at 200 dpi
9.5 x 218 inches (241 x 5537 mm) at 300 dpi
9.5 x 59 inches (241 x 1499 mm) at 400dpi and above
Capacity
100 pages of 20lb printer paper (80 g/m
2
)
Paper Thickness
7–110 lbs. (28–413 g/m
2
)
Plastic Card Embossed cards up to 1.25 mm thick
General Specifications
Scanning Speeds
• A4 Page Size
60 pages per minute / 120 images per minute @ 200/300 dpi
Optical Resolutions 600 dpi
Interpolated
Resolutions
75, 100, 150, 400, 500, and 1200 dpi
(these resolutions are available when Visioneer Acuity is installed)
Internal Bit Depth 48-bit color, 16-bit grayscale
Output Bit Depth 24-bit color, 8-bit grayscale
Scan Method Duplex Automatic Document Feeder (ADF)
Image Sensor CIS (Contact Image Sensors)
Light Source RGB LED
Interface USB 3.1Gen 1
Certifications ENERGY STAR 3, USB 3.1Gen 1, RoHS, CE, CB, WEEE, UL, C -UL, FCC Class B, EPEAT
(Bronze Minimum)

Xerox N60w Specifications

General

Color scanning	Yes
Background colors	Gray
Maximum scan size	- mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Quantity per pack	1 pc(s)
Cables included	LAN (RJ-45), USB
Bundled software	ABBYY FineReader 15 Standard OCR/PDF Software
Control type	Touch
Scanner type	ADF scanner
Product color	White
Display diagonal	8 \
Scan to	E-mail, FTP, PC, USB
Sensor type	CIS
Scan drivers	TWAIN, WIA
Daily duty cycle (max)	10000 pages
Windows operating systems supported	Windows 10, Windows 11, Windows 7
Auto document feeder (ADF) input capacity	100 sheets
Card thickness (max)	1.25 mm
Maximum scan area (ADF)	241 x 5994 mm
Minimum scan area (ADF)	51 x 51 mm
Scanning media types supported	Photo paper, Plain paper, Plastic Card
Maximum ISO A-series paper size	-
Auto Document Feeder (ADF) media weight	27 - 413 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Supported network protocols	HTTP, TCP/IP, SMTP, FTP, FTPS, SMB, DHCP, DNS, SMTP, LDAP, WEP 64/128, WPS/WPS2, TKIP
Online services supported	Evernote, Google Drive, OneDrive
USB version	3.2 Gen 1 (3.1 Gen 1)

Weight and Dimensions

Depth	207 mm
Width	316 mm
Height	178 mm
Weight	4700 g
