Disassembly and Reassembly
6. Remove the Holder Bearing(with Roller Exit F/Down)
from the both side of the Exit Frame, as shown below
and then remove the Roller Exit Main and Holder Exit
F/Down.
Holder Exit F/Down
Roller Exit Main
Holder Bearing
Exit Roller
Exit Gear
1
2
1
