Disassembly and Reassembly
5.24 Bypass/Auxiliary Tray
1. Remove the Cassette:
-
2. Push Down the MP Unit, as shown below.
3. Apply light pressure to the both side of the MP Unit
and pull it in the direction of arrow, as shown below.
1
2
MP Unit
