Xerox VersaLink B625 User Manual

Creating a Private Mailbox Folder
If the scan policy to allow additional folders is enabled, you can create a private mailbox folder. The system
administrator can create a private mailbox folder at any time. For details, refer to the System Administrator Guide at
www.xerox.com/office/VLB625docs.
To create a private mailbox folder with a password:
1. At your computer, open a Web browser, in the address field, type the IP address of the printer, then press EEnntteerr
or RReettuurrnn.
Note: For details about obtaining the IP address of your printer, refer to Finding the IP Address of Your
Printer.
2. Click the SSccaann tab.
3. In the Display section, select MMaaiillbbooxxeess.
Note: If the Display section does not appear, Scan to Mailbox is not enabled. For details, refer to the System
Administrator Guide at www.xerox.com/office/VLB625docs.
4. In the Scan to Mailbox section, click CCrreeaattee FFoollddeerr.
5. Click the FFoollddeerr NNaammee:: field, then type a name for the folder.
6. In the Folder Password field, type a password that adheres to the password rules.
7. In the Confirm Folder Password field, type the password again.
8. Click AAppppllyy.
Your private mailbox folder appears in the mailbox folder list in the Embedded Web Server and on the printer touch
screen under Pick a Workflow. The contents are stored on the printer hard drive.
Retrieving Scan Files from a Mailbox Folder
You can use the Embedded Web Server to retrieve scan files from a mailbox folder and copy the files to your
computer.
To retrieve your scan files:
1. At your computer, open a Web browser, in the address field, type the IP address of the printer, then press EEnntteerr
or RReettuurrnn.
Note: For details about obtaining the IP address of your printer, refer to Finding the IP Address of Your
Printer.
2. Click the SSccaann tab.
3. In the Display section, select MMaaiillbbooxxeess.
4. In the Scan to Mailbox section, click the folder containing the scan.
Note:
• For a password protected private folder, click the FFoollddeerr PPaasssswwoorrdd field, type the password, then click
OOKK.
• If your image file does not appear, click UUppddaattee VViieeww.
Your scan file appears in the Folder Contents window.
128
Xerox
®
VersaLink
®
B625 Multifunction Printer User Guide
Xerox
®
Apps

Xerox VersaLink B625 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	2.9 s
Time to first page (black, normal)	4.1 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Storage media	eMMC
Internal memory	4096 MB
Processor cores	4
Internal storage capacity	32 GB
Sound power level (standby)	32 dB
Sound power level (printing)	72 dB
Sound pressure level (standby)	14 dB
Sound pressure level (printing)	56 dB
Custom media width	98.4 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	191 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 176 g/m²
ISO A-series sizes (A0...A9)	A4, A4+, A5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 120 g/m²
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, 802.1x RADIUS, FIPS 140-3, HTTPS, IPSec
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
Supported network protocols (IPv6)	IPv6
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Scan to	E-mail, E-mail Server, File, Network folder, OCR, PC, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Maximum scan area	215.9 x 355.6 mm
Output color depth	24 bit
Scan speed (black)	75 ppm
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	3850 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	200 sheets
Current rating	5.3 A
Browser supported	Brave Browser, Chrome, Microsoft Edge, Mozilla Firefox, Opera, Safari
Maximum scan area (ADF)	216 x 355 mm
Minimum scan area (ADF)	76 x 127 mm
Copier resize	25 - 400 %
Maximum number of copies	9999 copies
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650 mm
Package width	550 mm
Package height	565 mm
Package weight	28900 g
Control type	Touch
Product color	Black, Grey
Display diagonal	7 \
Market positioning	Business
USB connector	USB Type-A / USB Type-B
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	796 W
Power consumption (off)	1.7 W
Power consumption (standby)	31 W
Faxing	Color faxing
Fax resolution (color)	400 x 400 DPI
Included cartridge capacity (black)	10000 pages
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8, Windows 8.1

Weight and Dimensions

Depth	578.4 mm
Width	558.8 mm
Height	739.1 mm
