Xerox VersaLink B625 User Manual

Label and Envelope Misfeeds
PPRROOBBAABBLLEE CCAAUUSSEESS SSOOLLUUTTIIOONNSS
The label sheet is facing the wrong way in the tray. Load label sheets according to the instructions from
the manufacturer.
Load labels face down in standard Trays 1–4 and
Bypass Tray.
For loading labels with correct orientation, refer to
Labels.
Note: Do not load labels in the High Capacity
Feeder Tray.
Envelopes are loaded incorrectly or in the wrong tray. Use standard Trays 1–4 and Bypass Tray to print
envelopes.
For loading envelopes with correct orientation, refer to
Envelopes.
Envelopes are loaded incorrectly in Bypass Tray. To load envelopes in Bypass Tray:
• For envelopes with the flap on a long edge, load
envelopes with the flaps face down and closed.
Keep the flaps toward the left.
• For envelopes with the self-seal or non-adhesive
flap on a short edge, load envelopes with the flaps
face down and closed. Insert the envelopes with the
flaps toward the feed direction.
• For the custom-size envelopes, when the flap is on
the short edge and the long edge is longer than
216 mm (8.5 in.), load envelopes with the flaps
face down and closed. Insert the envelope with the
flap toward the feed direction. For custom-size
envelopes, define the custom size on the control
panel.
Note: Unless the long edge is longer than 216
mm (8.5 in.) or the short edge is less than the
minimum width of the feeder, the flap of the
envelop should always be to the left.
Paper Jam Message Stays On
PPRROOBBAABBLLEE CCAAUUSSEESS SSOOLLUUTTIIOONNSS
Some paper remains jammed in the printer. Recheck the media path and make sure that you have
removed all of the jammed paper.
One of the printer doors is open. Check the doors on the printer. Close any door that is
open.
Xerox
®
VersaLink
®
B625 Multifunction Printer User Guide 271
Troubleshooting

Xerox VersaLink B625 Specifications

General

N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	2.9 s
Time to first page (black, normal)	4.1 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Storage media	eMMC
Internal memory	4096 MB
Processor cores	4
Internal storage capacity	32 GB
Sound power level (standby)	32 dB
Sound power level (printing)	72 dB
Sound pressure level (standby)	14 dB
Sound pressure level (printing)	56 dB
Custom media width	98.4 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	191 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 176 g/m²
ISO A-series sizes (A0...A9)	A4, A4+, A5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	52 - 120 g/m²
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, 802.1x RADIUS, FIPS 140-3, HTTPS, IPSec
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
Supported network protocols (IPv6)	IPv6
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	PCL 5c, PCL 6, PDF, PostScript 3
Scan to	E-mail, E-mail Server, File, Network folder, OCR, PC, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Maximum scan area	215.9 x 355.6 mm
Output color depth	24 bit
Scan speed (black)	75 ppm
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	3850 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	200 sheets
Current rating	5.3 A
Browser supported	Brave Browser, Chrome, Microsoft Edge, Mozilla Firefox, Opera, Safari
Maximum scan area (ADF)	216 x 355 mm
Minimum scan area (ADF)	76 x 127 mm
Copier resize	25 - 400 %
Maximum number of copies	9999 copies
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650 mm
Package width	550 mm
Package height	565 mm
Package weight	28900 g
Control type	Touch
Product color	Black, Grey
Display diagonal	7 \
Market positioning	Business
USB connector	USB Type-A / USB Type-B
Optional connectivity	Bluetooth, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	796 W
Power consumption (off)	1.7 W
Power consumption (standby)	31 W
Faxing	Color faxing
Fax resolution (color)	400 x 400 DPI
Included cartridge capacity (black)	10000 pages
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 11, Windows 8, Windows 8.1

Weight and Dimensions

Depth	578.4 mm
Width	558.8 mm
Height	739.1 mm
