Xerox VersaLink B625

8. Close Door A.
Clearing Jams at Door C
To clear the paper jams from inside the printer rear door, Door C, do the following:
1. Open Door C.
CCaauuttiioonn:: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow
the surface of the printer to cool down before touching.
2. Remove the jammed paper that is present above the fuser assembly.
Xerox
®
VersaLink
®
B625 Multifunction Printer User Guide 267
Troubleshooting
