a. For short-edge feed printing, load letterhead and pre-printed paper face down with the top edge toward
the feed direction of the paper.
Long-edge feed is the recommended orientation for A5 (148 x 210 mm, 5.8 x 8.3 in.) paper.
WWaarrnniinngg:: Do not load paper above the maximum fill line. Overfilling can cause paper jams.
b. For hole-punched paper, load the paper short-edge feed with the holes at the right side of the paper.
5. Adjust the width guides until they touch the edges of the paper.
Xerox
®
VersaLink
®
B625 Multifunction Printer User Guide 205
Paper and Media
