Chapter 3: Board Component Descriptions
M25 RLD3_C3_72B_DQ45 SSTL12 J10 DQ9 U142
L26 RLD3_C3_72B_DQ46 SSTL12 K11 DQ10 U142
L28 RLD3_C3_72B_DQ47 SSTL12 K13 DQ11 U142
K28 RLD3_C3_72B_DQ48 SSTL12 L8 DQ12 U142
L24 RLD3_C3_72B_DQ49 SSTL12 L10 DQ13 U142
L25 RLD3_C3_72B_DQ50 SSTL12 L12 DQ14 U142
K26 RLD3_C3_72B_DQ51 SSTL12 M9 DQ15 U142
J26 RLD3_C3_72B_DQ52 SSTL12 M11 DQ16 U142
K27 RLD3_C3_72B_DQ53 SSTL12 N8 DQ17 U142
H27 RLD3_C3_72B_DQ54 SSTL12 D3 DQ18 U142
G27 RLD3_C3_72B_DQ55 SSTL12 E4 DQ19 U142
F28 RLD3_C3_72B_DQ56 SSTL12 C6 DQ20 U142
E28 RLD3_C3_72B_DQ57 SSTL12 C4 DQ21 U142
H28 RLD3_C3_72B_DQ58 SSTL12 C2 DQ22 U142
G28 RLD3_C3_72B_DQ59 SSTL12 B5 DQ23 U142
E26 RLD3_C3_72B_DQ60 SSTL12 B3 DQ24 U142
E27 RLD3_C3_72B_DQ61 SSTL12 A6 DQ25 U142
G25 RLD3_C3_72B_DQ62 SSTL12 A4 DQ26 U142
B28 RLD3_C3_72B_DQ63 SSTL12 J4 DQ27 U142
A28 RLD3_C3_72B_DQ64 SSTL12 K3 DQ28 U142
C27 RLD3_C3_72B_DQ65 SSTL12 K1 DQ29 U142
B27 RLD3_C3_72B_DQ66 SSTL12 L6 DQ30 U142
B26 RLD3_C3_72B_DQ67 SSTL12 L4 DQ31 U142
A26 RLD3_C3_72B_DQ68 SSTL12 L2 DQ32 U142
D25 RLD3_C3_72B_DQ69 SSTL12 M5 DQ33 U142
D26 RLD3_C3_72B_DQ70 SSTL12 M3 DQ34 U142
C25 RLD3_C3_72B_DQ71 SSTL12 N6 DQ35 U142
N24 RLD3_C3_72B_DM2 SSTL12 B7 DM0 U142
B25 RLD3_C3_72B_DM3 SSTL12 M7 DM1 U142
T26 RLD3_C3_72B_QK4_P DIFF_SSTL12 D9 QK0 U142
R26 RLD3_C3_72B_QK4_N DIFF_SSTL12 E8 QK0_B U142
M27 RLD3_C3_72B_QK5_P DIFF_SSTL12 K9 QK1 U142
M28 RLD3_C3_72B_QK5_N DIFF_SSTL12 J8 QK1_B U142
G26 RLD3_C3_72B_QK6_P DIFF_SSTL12 D5 QK2 U142
Table 3-4: RLD3 Memory 72-bit I/F to FPGA U1 Banks 46, 47, and 48 (Cont’d)
FPGA
(U1) Pin
Schematic Net Name I/O Standard
Component Memory
Pin # Pin Name Ref. Des.
