104 Viewing Status on the Wireless Array
License
 License: The license key of each Array.
 Licensed Features: Lists the features enabled by the key.
Software (enabled by default)
 Enable/disable display of the Array OS column.
Firmware
 Boot Loader: The software version number of the boot loader on each
Array.
 SCD Firmware: The software version number of the SCD firmware on
each Array.
IAP Info (enabled by default)
 Enable/disable display of the IAP/Up columns.
Stations
 Stations: Tells you how many stations are currently associated to each
Array. To de-authenticate a station, go to “Stations” on page 123.
The columns to the right (H, D, W, and M) show the highest number of
stations that have been associated over various periods of time: the
previous hour, day, week, and month.
Default
 Sets the columns displayed to the default settings. By default, only
Software and IAP Info are selected.
