Wireless Array
120 Viewing Status on the Wireless Array
Radio Assurance
When Radio Assurance mode is enabled, the monitor radio performs loopback
tests on the Array’s radios. When problems are encountered, the Array can take
various actions to correct them by performing different levels of reset on the
affected radio. This window shows which resets, if any, have been performed on
which radios since the last reboot.
The Array’s response to radio problems is controlled by the Radio Assurance
Mode selected, as described in “RF Resilience” on page 335. If you have selected
Failure Alerts & Repairs (with or without reboots), then the Array can take
corrective action if a problem is detected. Note that radio assurance requires RF
Monitor Mode to be enabled in Advanced RF Settings to turn on self-monitoring
functions. It also requires a radio to be set to monitoring mode. For a detailed
discussion of the operation of this feature and the types of resets performed, see
“Radio Assurance” on page 501.
Figure 67. Radio Assurance
For each of the Array’s radios, this window shows the radio’s state, its type (IEEE
802.11 type, and antenna type—2x2 or 3x3), the assigned channel, and the selected
802.11 wireless mode. To the right, the table shows counts for the number of
times, if any, that radio assurance has performed each of the following types of
resets since the last reboot, as described in Radio Assurance:
Monitor
Beacon
Phy
MAC
System (i.e., reboot the Array)
