Wireless Array
Installing the Wireless Array 25
Installing the Wireless Array
The instructions for completing a successful installation include the following
topics:
“Installation Prerequisites” on page 25.
“Planning Your Installation” on page 28.
“Installation Workflow” on page 61.
“Installing Your Wireless Array” on page 63.
“Powering Up the Wireless Array” on page 66.
“Zero-Touch Provisioning and Ongoing Management” on page 69.
“Performing the Express Setup Procedure” on page 75.
Installation Prerequisites
Your Wireless Array deployment requires the presence of hardware and services
in the host wired/wireless network, including:
Power Source
Xirrus Arrays and APs are powered via Xirrus-supplied Power over
Gigabit Ethernet. PoGE supplies power over the same Cat 5e or Cat 6
cable used for data, thus reducing cabling and installation effort. PoGE
power injector modules are available in 1-, 2-, and 8-port configurations
and are typically placed near your Gigabit Ethernet switch. An AC outlet
is required for each injector module.
Some smaller Arrays and APs are compatible with IEEE802.3af and/or
IEEE802.3at, and may be connected to appropriate powered switches. For
example, the Xirrus XT-5024 is a 24-port 802.3at PoE+ managed switch.
See the Quick Installation Guide for the Array/AP for compatible
injectors or powered switches.
ArrayEthernet ports
You need at least one 100/1000 BaseT port to establish wired Gigabit
Ethernet connectivity. XR Series Arrays have different numbers of ports,
