VX-6E OPERATING MANUAL 91
SET
(
MENU
)
M
ODE
SET MODE ITEM
7 [BEEP]
9 [BP LVL]
11 [BSY.LED]
28 [HM/RV]
33 [LAMP]
35 [LOCK]
36 [M/T-CL]
SET MODE ITEM
62 [SU1.ALT]
63 [SU1.BRM]
64 [SU1.SET]
SET MODE ITEM
16 [DC VLT]
19 [DIMMER]
65 [TEMP]
SET MODE ITEM
1 [APO]
5 [ATT]
6 [BCLO]
12 [CH CNT]
13 [CLK.SFT]
15 [CWTRNG]
25 [EDG.BEP]
27 [HLF.DEV]
34 [LED LT]
37 [MCGAIN]
41 [ON TMR]
42 [OPN.MSG]
47 [PSWD]
48 [PTT.DLY]
50 [RF SQL]
52 [RX MD]
54 [S SRCH]
58 [SPLIT]
61 [STEP]
67 [TOT]
71 [VFO MD]
AVAILABLE VALUES
(
DEFAULT
)
ON / OFF
LVL 1 - LVL 9 (LVL 5 )
ON / OFF
REV / HOME
KEY / CONT / OFF
KEY / DIAL / K+D / PTT /
P+K / P+D / ALL
MONI / T-CALL
Ú2
AVAILABLE VALUES
(
DEFAULT
)
M / Ft
Ú2, 3
Offset: –1000 - 0 - +1000
HP / MB / HG / IC
Ú2, 3
Offset: –1000 - 0 - +1000
OFF / BARO / ALTI
Ú3
AVAILABLE VALUES
(
DEFAULT
)
--
LVL 0 - LVL 12 (LVL 7)
--
AVAILABLE VALUES
(
DEFAULT
)
OFF / 30MIN / 1HOUR / 3HOUR /
5HOUR / 8HOUR
OFF / ON
OFF / ON
±5 MHz / ±10 MHz / ±50 MHz /
±100 MHz
OFF / ON
OFF / 4WPM-13WPM / 15WPM /
17WPM / 20WPM / 24WPM /
30WPM / 40WPM
(20CPM - 65CPM (5CPM multiples)
/ 75CPM / 85CPM /100CPM /
120CPM / 150CPM / 200CPM)
OFF / ON
OFF / ON
---
LVL 1 - LVL 10 (LVL 5)
OFF /
00H10M (00:10) - 24H00M (24:00)
(10 minutes multiples)
DC / MSG / OFF
--
OFF / 20MS / 50MS / 100MS /
200MS
OFF / S1 / S2 / S3 / S4 /
S5 / S6 / S7 / S8 / S9 / S9+
AUTO / N-FM / AM / W-FM
SINGLE / CONT
OFF / ON
5.0k / 10.0k / 12.5k / 15.0k / 20.0k /
25.0k / 50.0k / 100.0k / AUTO
OFF / 1MIN / 3MIN / 5MIN / 10MIN
BAND / ALL
SWITCH/KNOB SETTING
Enables/Disables the keypad beeper.
Adjust the Beep volume level.
Enables/Disables the BUSY LED while the Squelch is open.
Selects the Primary function of the [HM/RV(EMG)R/H] key.
Selects the LCD/Keypad Lamp mode.
Selects the Control Locking lockout combination.
Selects the MONI switch (just below the PTT switch) function.
SU-1 SETTING
Selects the measurement units for the altimeter, and correcting the altimeter.
Selects the measurement units for the Barometric Pressure, and correcting the Barometric Pres-
sure.
Selects the display of the sensor units’ information.
DISPLAY SETTING
Indicates the DC Supply Voltage
Setting of the Display brightness level.
Indicates indicate the current temperature inside the transceivre’s case and selects the mea-
surement units (“°F” or “°C”) for the temperature sensor.
MISCELLANEOUS SETTING
Setting of the Automatic Power-Off feature.
Enables/Disables the Receiver Front-end (10 dB) Attenuator.
Enables/Disables the Busy Channel Lock-Out feature.
Selects the Channel Counter Search Width.
Shifting of the CPU clock frequency.
Enables/Disables the CW Training feature and selects the sending speed of the Morse Code.
Enables/Disables the Band-edge beeper while selecting the frequency via the DIAL knob.
Reducing the Deviation level by 50 %.
Illuminates the STROBE glows continuously in white.
Adjust the microphone gain level.
Set the ON Timer time.
Selects the Opening Message that appears when the radio is powered on.
Programs and activates the Password feature.
Select the time delay between when the PTT switch is pressed and the carrier is transmitted.
Adjusts the RF Squelch threshold level.
Selects the receiving mode.
Selects the Smart Search Sweep mode.
Enables/Disables split CTCSS/DCS coding.
Setting of the synthesizer steps.
Setting of the TOT time
Enables or disables the VFO band edge limiting for the current band.
Ú
1: Depends on the frequency band.
Ú
2: Depends on the transceiver version.
Ú
3: Requires optional SU-1.
