Operation and handling requirements
104
Engine compartment
1 Fuel tank compartment drain plug
To drain the bilge water from the hull:
Remove the hull drain plugs at the stern to
drain the water. Check the condition of the O-
rings on the hull drain plugs, and then secure-
ly install the drain plugs.
1 Hull drain plug
Draining the bilge water on water
This model is equipped with a self-draining
deck and bilge pump to drain the bilge water
on water.
Self-draining deck
Most water that enters the deck area drains
automatically out the stern through the large
drain hole in the deck.
A one-way check valve in the drain prevents
water from traveling back to the deck while
the boat is moored or moving in reverse.
Bilge pump
Your boat is equipped with a drainage sys-
tem that channels water that enters the boat
from the storage compartments to the bilge
under the engine compartment.
When the bilge pump switch is turned on, the
bilge pump will operate.
1 Bilge pump switch
HORNBILGENAV/ANC
CTSY
LIGHTS
1
