Equipment operation
91
1 Ladder
(2) Pull the ladder out completely, and then
lower it.
To stow the ladder:
(1) Raise the ladder until it is horizontal, and
then push it forward completely.
(2) Push the end of the ladder to fit it onto
the hooks on the boat.
1 Hook
Side table
The side table can be installed in front of the
rear starboard seat.
1 Side table
To install the side table, slide the end of the
table pole into the table bracket until it is
locked in place.
1 Table bracket
2 Ta b le p ole
3 Table bracket knob
To remove the side table, pull the table brack-
et knob, and then pull the table pole upward.
1
1
1
1
3
2
