Equipment operation
93
To collapse the wakeboard tower:
(1) While an assistant supports the wake-
board tower, completely loosen the lock
knobs on both sides of the wakeboard
tower.
1 Wakeboard tower
2 Lock knob
(2) Lower the wakeboard tower until it
stops.
To set up the wakeboard tower:
(1) Lift the wakeboard tower.
(2) While an assistant supports the wake-
board tower, tighten the lock knobs on
both sides of the wakeboard tower until
they stop.
Bimini top
(195S / AR195 / AR190)
Setting up the bimini top
To set up the bimini top:
(1) Remove the storage cover, and then un-
wrap the bimini top.
1 Storage cover
(2) Pull the front of the bimini top toward the
bow, and then open the flap and pull out
the front support poles from the bimini
top.
1 Front support pole
2 Flap
