Yamaha AR190 2021 - Walk-Through; Front Walk-Through; Rear Walk-Through

Equipment operation
86
1 Wet storage compartment
To close the wet storage compartment:
(1) Close the rear platform hatch.
(2) Turn the lock handle counterclockwise
and make sure that the hatch is securely
closed.
(3) Push the lock handle down.
TIP:
The engine will not start if the rear platform
hatch is not securely closed.
Walk-through
Front walk-through
This boat has a large bow area where two
adults can sit comfortably with their legs out-
stretched. The front walk-through provides
easy access to the bow area from the cabin
area.
1 Front walk-through
Rear walk-through
The backrest of the rear center seat is low in
order to make boarding the boat from the
rear easier.
1 Rear walk-through
1
1
1
