Description
33
Engine components
195S / AR195 / SX195
1 Fuse box (cover) (page 151)
2 Engine oil filler cap (page 101)
3 Blower (page 113)
4 Engine cover (page 139)
5 Air filter case
6 Dipstick (page 101)
7 Spark plug/Ignition coil
7
21
3
4
5
6
