Instrument operation
67
Screen tab bar
Center display
3 Engine tachometer Displays the engine speed.
4 Battery voltage bar graph Displays the battery voltage in a bar graph format and numerical
format.
Name Function
1 Clock Displays the time. Tap the clock to set the time. (See page 70.)
2 Home screen tab Displays the home screen. (See page 69.)
3 Trip screen tab Displays the trip screen. (See page 69.)
4 Setting screen tab Displays the setting screen. (See page 70.)
5 Mute Mutes the sound of the buzzer for a specific time depending on
the warnings present.
Name Function
1 Center display Displays various information for each screen.
Name Function
am10:27
321 54
MPH
0
0.3 Avg MPG
1
