Equipment operation
87
Windshield
The windshield can be opened and closed.
WARNING
To avoid injury, the windshield must be se-
cured when the boat is in motion.
To close the windshield:
(1) Unsnap the retaining strap from the
windshield, and then snap it onto the
strap base.
1 Retaining strap
2 Strap base
(2) Close the windshield, and then turn the
windshield latches to the lock position.
1 Windshield latch
To open the windshield:
(1) Turn the windshield latches to the unlock
position, and then open the windshield.
(2) Unsnap the retaining strap from the strap
base, and then snap it onto the wind-
shield.
Mirror (195S / AR195 / AR190)
The mirror is attached on the center of the
windshield.
1 Mirror
The mirror can be moved up, down, to the
left, and to the right to adjust the mirror angle.
1
2
1
1
